Bridgeport’s high specification V-Series Vertical Machining Centres (VMCs) are extremely compact and rugged mills; developed for applications that require both the utmost in speed and accuracy.
5-Axis VMC
Bridgeport’s high specification V-Series Vertical Machining Centres (VMCs) are extremely compact and rugged mills; developed for applications that require both the utmost in speed and accuracy.
Standard Features
Optional Features
For more information, download the flyer and spec sheet above, click the 'Request a Quote' button above, or call us on 01924 415 000.
| X-Axis travel (mm) | 510 |
|---|---|
| Y-Axis travel (mm) | 610 |
| Z-Axis travel (mm) | 510 |
| 5-Axis rotary table diameter (mm) | 320 |
| 5-Axis rotary table tilting A-Axis (Degrees) | +30 / -120 |
| 5-Axis rotary table rotation C-Axis (Degrees) | 360 |
| T-Slot (No. & size) (mm) | 4 x 12 |
| Load capacity (kg) | Vertical = 100 / Horizontal = 150 |
| Spindle taper | BT 40 (BBT 40 option) |
| Spindle Speed (rpm) | 10,000 |
| Tool capacity (Tools) | 30 |
| Automatic Tool Changer (ATC) type | Swing arm |
| CNC control | Siemens Sinumerik ONE 15" |
